stu.waller

So an update on readings. Been back out to do a better job of recording voltages. Multimeter on car ground to the following pins: with ignition on but not running Pin 1- 4.98v Pin 2- 0v Pin 3- 12.19v Multimeter on car ground to the following pins: car running Pin 1- 4.99v Pin 2- 0v Pin 3- 14.37v - 14.45v when rev'd Variance between pins 1 and 3 - 9.3v And pins 2 and 3 - 14.4v All seems normal yet something blows the maf sensor. Could the Multimeter response time be insufficient to pick up voltage transients? What am I missing here? If anyone could provide their voltage readings as a comparison it would be appreciated. If anyone has any ideas of what to look at next, that'd also be appreciated. Would different measurement equipment be more suitable? Oscilloscope?

Hi All. Would really appreciate some support with an issue that has confused audi specialists. The MAF sensor keeps on blowing. When it does the car cuts out. Unplug the sensor, the car runs ok, but over fuels. Putting a multimeter on the ground pin in the wiring plug, the next to the middle pin I get 4.99 volts which I think is correct. If I them check the next pin I get 7.3 volts with ignition on and 9.5 volts with the engine running. I thought this was supposed to be considerably less? If that's the case any ideas where to start? Anyone know where I can get a schematic for the actual ECU? I'd like to track back through the loom and find where the excessive voltage is coming from. All help will be very much appreciated. Stu
