ThomasG

Thank-you so much!! T

No, nothing. That's odd. I can see you've read my message. But nothing from you. Do you just want to post part numbers here?

Not yet, but will wait. Think I may have found the part regardless. Also, think I may invest in a trolley jack !! Thanks

Right, driven along the local runway (where Jim Clark used to practice). So was totally level. No issues. Road for a bit, and errors after a few miles.

Aye, but how do I go about testing this, and I can't seem to find a replacement one.

Looking at the scan again, it seems front right level sensor may be the culprit. Its all fine now. No lights. It triggers when driving. I'll keep digging.

Actually, that was the wrong info. Here is full scan. I know there is some issues withe the a/c - it's the other stuff that is new and worrying. --------------------------------------------------------------- 01 Engine System description: 3.0BTD EDC17 Software number: 4G0907589C Software version: 0001 Hardware number: 4G0907589 Hardware version: H25 ODX name: EV_ECM30BTD0114G0907589C ODX version: 001001 Long coding: 322A403225760B020000 Trouble codes: No trouble codes found --------------------------------------------------------------- 02 Transmission System description: 0BK 30RTDIRdW Software number: 4G0927158L Software version: 1003 Hardware number: 0BK927156AM Hardware version: H16 ODX name: EV_TCMAL551211 ODX version: 002022 Long coding: 000001 Trouble codes: No trouble codes found --------------------------------------------------------------- 03 Brakes System description: ESP PREMIUM Software number: 4G0907379M Software version: 0450 Hardware number: 4G0907379M Hardware version: H09 Serial number: -------------- ODX name: EV_ESPPremiAU57X ODX version: 004039 Long coding: 49A7DF0592E5FBA0FB00 Trouble codes: No trouble codes found --------------------------------------------------------------- 04 Steering Angle Sensor Trouble codes: No trouble codes found --------------------------------------------------------------- 05 Keyless System System description: BCM2 2.0 Software number: 4H0907064CN Software version: 0433 Hardware number: 4H0907064CN Hardware version: H33 Long coding: 01B93046000000000000 Subsystems: System description: J764 ELV MLB Software number: 4H0905852C Software version: 0046 Hardware version: H40 Serial number: 2313000106737005 Trouble codes: No trouble codes found --------------------------------------------------------------- 08 Air Conditioning System description: KLIMA 4 ZONEN Software number: 4G0820043AD Software version: 0087 Hardware number: 4G0820043AD Hardware version: H13 Serial number: 22061300040258 ODX name: EV_AirCondiComfoUDS ODX version: 002040 Long coding: 3622007825 Trouble codes: U111300 - Function limitation due to received malfunction value static Date: 2020-06-19 20:01:36 Mileage: 132847 km Priority: 6 Malfunction frequency counter: 1 Unlearning counter: 191 Dynamic environmental data: 02860BC326098C26131AF4 B109E13 - A/C compressor first run Open circuit static Date: 2020-06-19 20:01:36 Mileage: 132847 km Priority: 6 Malfunction frequency counter: 1 Unlearning counter: 191 Dynamic environmental data: 02860BC326098C26131AF4 B126411 - Windshield defogger activation Short circuit to ground static Date: 2020-06-19 20:01:36 Mileage: 132847 km Priority: 6 Malfunction frequency counter: 1 Unlearning counter: 191 Dynamic environmental data: 02860BC326098C26131AF4 B126412 - Windshield defogger activation Short circuit to B+ static Date: 2020-06-19 20:01:36 Mileage: 132847 km Priority: 6 Malfunction frequency counter: 1 Unlearning counter: 191 Dynamic environmental data: 02860BC326098C26131AF4 --------------------------------------------------------------- 09 Central Electrics System description: BCM1 2.0 Software number: 4H0907063CE Software version: 0130 Hardware number: 4H0907063E Hardware version: H12 Serial number: 00000001745791 Long coding: 0200201050B49FE2C98100C000001908CF9D67082F080201000008406100 Subsystems: System description: WWS57X 130618 Software number: 4G2955119 Software version: 0080 Hardware version: H36 Serial number: 130620152538 Long coding: 0045F7 System description: G397_RLFS Software number: 8U0955559B Software version: 0002 Hardware version: H06 Serial number: 21462662 Long coding: 02006D System description: E1 - LDS Software number: 4G0941531S Software version: 0044 Hardware version: H07 Serial number: 28 06 2013 00001337 System description: AQ_Hum_Sensor Software number: 4H0907658 Software version: 0003 Hardware version: H03 Serial number: 7719C4B6000000000001 Trouble codes: 01229 - Humidity sensor, A/C system Faulty static Priority: 3 Frequency counter: 1 Driving cycle: 191 Mileage: 132847 km Date: 2020-06-19 20:01:00 01771 - Headlamp range control module Please read DTC static Priority: 6 Frequency counter: 1 Driving cycle: 192 Mileage: 132860 km Date: 2020-06-20 15:36:00 --------------------------------------------------------------- 10 Parking Assistance System description: PARKHILFE PLA Software number: 4H0919475AB Software version: 0060 Hardware number: 4H0919475E Hardware version: H06 Serial number: 56261318003980 ODX name: EV_EPHVA2CAU57X0000 ODX version: 002012 Long coding: B93B0C Trouble codes: No trouble codes found --------------------------------------------------------------- 13 Adaptive Cruise Control System description: ACC3 Software number: 4G0907561A Software version: 0410 Hardware number: 4G0907561 Hardware version: H19 Serial number: 00000000000000 ODX name: EV_AdaptCruisContrAU57X ODX version: 002010 Long coding: 7F04010202 Trouble codes: U111300 - Function limitation due to received malfunction value static Date: 2020-06-20 15:36:48 Mileage: 132860 km Priority: 6 Malfunction frequency counter: 2 Unlearning counter: 192 Dynamic environmental data: 028D001A028537F7100E1619100FFCF4 --------------------------------------------------------------- 15 Airbag System description: Airbag10.43 Software number: 4H0959655C Software version: 0040 Hardware number: 4H0959655C Hardware version: H43 Serial number: 003JG00DVSXE ODX name: EV_AirbaAU10BPAAU64X ODX version: 001014 Long coding: 3032343631334E303539554A305234473053 Trouble codes: No trouble codes found --------------------------------------------------------------- 16 Steering Column System description: Lenks.Modul Software number: 4H0953568G Software version: 0005 Hardware number: 4H0953568G Hardware version: H04 Serial number: 90372MFR001G3 Long coding: 0000FD Subsystems: System description: E221 - MFL Software number: 4G0951528E Software version: 0010 Hardware version: H09 Serial number: 22 05 2013 33011847 Trouble codes: No trouble codes found --------------------------------------------------------------- 17 Dashboard System description: TDieGb AccNv Software number: 4G9920950P Software version: 0618 Hardware number: 4G9920950P Hardware version: H80 Serial number: 6581406135960075 ODX name: EV_RBD4K ODX version: 004048 Long coding: 338720081F512600010600 Trouble codes: No trouble codes found --------------------------------------------------------------- 19 Gateway System description: J533--Gateway Software number: 4G0907468AC Software version: 0037 Hardware number: 4G0907468AC Hardware version: H12 Serial number: 00000000999979 ODX name: EV_GatewPkoUDS ODX version: 001018 Long coding: 00CD077D00 Subsystems: System description: J367-BDMHella Software number: 8T0915181 Software version: 8041 Hardware version: H03 Serial number: 8141390603 Trouble codes: No trouble codes found --------------------------------------------------------------- 28 Rear Climate Control System description: KLIMA FOND Software number: 4G0919158J Software version: 0087 Hardware number: 4G0919158J Hardware version: H07 Serial number: 03071300040346 ODX name: EV_ClimaContrUnitRearUDS ODX version: 002019 Long coding: 22 Trouble codes: B10D322 - Left rear upper body vent motor Upper limit exceeded Intermittent Date: 2020-06-20 15:05:26 Mileage: 132847 km Priority: 3 Malfunction frequency counter: 1 Unlearning counter: 232 Dynamic environmental data: 02860D4926099026A62EE92EE92C902710 B10D422 - Right rear upper body vent motor Upper limit exceeded Intermittent Date: 2020-06-20 15:05:27 Mileage: 132847 km Priority: 3 Malfunction frequency counter: 1 Unlearning counter: 232 Dynamic environmental data: 02860D4E26099026A72EDD2EDD2C842710 --------------------------------------------------------------- 34 Chassis Control System description: LUFE-DAEMPFER Software number: 4G0907553F Software version: 0782 Hardware number: 4G0907553F Hardware version: H18 Serial number: �‰ST ODX name: EV_AirSuspe ODX version: 003024 Long coding: 008003 Trouble codes: C103515 - Right front level control sensor Open circuit/short circuit to B+ static Date: 2020-06-20 15:36:46 Mileage: 132860 km Priority: 2 Malfunction frequency counter: 1 Unlearning counter: 192 --------------------------------------------------------------- 3B Sensor Electronics System description: SARA 6D Software number: 4G0907637K Software version: 0056 Hardware number: 4G0907637F Hardware version: H02 Serial number: EJ1BPA82044ZLP���������� ODX name: EV_SARA2 ODX version: 005012 Trouble codes: No trouble codes found --------------------------------------------------------------- 3C Lane Change Assistant Right System description: J769 SWA MasterH04 Software number: 4G0907566E Software version: 0040 Hardware number: 4G0907566 Serial number: 6PZ 010 287-04 Coding: 0011104 Subsystems: System description: J770 SWA Slave H04 Software number: 4G0907568E Software version: 0040 Trouble codes: No trouble codes found --------------------------------------------------------------- 42 Driver Door System description: TSG FA Software number: 4G8959793H Software version: 0507 Hardware number: 4G8959793F Hardware version: H04 Serial number: -------------- Long coding: 011F16005C01628002080013 Trouble codes: No trouble codes found --------------------------------------------------------------- 44 Steering Assistance System description: RCEPS Software number: 4G0909144L Software version: 0010 Hardware number: 4G0909144G Hardware version: H38 Serial number: 0029630591 ODX name: EV_RCEPS ODX version: 009008 Long coding: 101101010000 Trouble codes: No trouble codes found --------------------------------------------------------------- 46 Comfort System System description: BCM2 2.0 Software number: 4H0907064CN Software version: 0433 Hardware number: 4H0907064CN Hardware version: H33 Serial number: 0310530050 Long coding: 013B0622A0B93080832009042C010F470000000000000000000000000000 Subsystems: System description: DWA-Sensor Software number: 4G0951177 Software version: 0010 Hardware version: H01 System description: LIN BACKUP HO Software number: 1K0951605C Software version: 1501 Hardware version: H05 Trouble codes: No trouble codes found --------------------------------------------------------------- 47 Sound System System description: BOSE-G3-C7 Software number: 4G0035223C Software version: 0160 Hardware number: 4G0035223A Hardware version: H07 Serial number: 00000000019648 Long coding: 030000 Trouble codes: No trouble codes found --------------------------------------------------------------- 52 Passenger Door System description: TSG BF Software number: 4G8959792J Software version: 0507 Hardware number: 4G8959792G Hardware version: H03 Serial number: -------------- Long coding: 011F16005E01628002080002 Trouble codes: No trouble codes found --------------------------------------------------------------- 53 Parking Brake System description: EPB-4 Software number: 4H0907801L Software version: 0017 Hardware number: 4H0907801A Hardware version: H05 Serial number: 00000002610471 ODX name: EV_ParkiBrake ODX version: 001029 Trouble codes: No trouble codes found --------------------------------------------------------------- 55 Headlight Regulation System description: ....AFS13.... Software number: 4H4907357C Software version: 0020 Hardware number: 4H4907357A Hardware version: H01 Serial number: 130628-0004-0076 ODX name: EV_AdvanFrontSyste ODX version: 005001 Long coding: 11226F33F918EB00 Trouble codes: U111200 - Function limitation due to implausible message static Date: 2020-06-20 15:36:47 Mileage: 132860 km Priority: 6 Malfunction frequency counter: 1 Unlearning counter: 192 --------------------------------------------------------------- 56 Radio System description: Radio U DAB Software number: 4G0035061S Software version: 0154 Hardware number: 4G0035061 Hardware version: H60 Serial number: 109GB0D7689099 Long coding: 010103010000000001 Trouble codes: No trouble codes found --------------------------------------------------------------- 5F Multimedia System description: H-BNT-EU Software number: 4G0035670Q Software version: 1034 Hardware number: 4G0035670H Hardware version: H51 Serial number: 190G$0D7544157 Long coding: 080101050003F9EF3D90EB3E00000003000001000200000000 Subsystems: System description: EUR 2020 Software number: 8R0060884GS Software version: 3001 System description: DU8 C7 SV Software number: 4G0919605C Software version: 0021 Hardware version: H43 Serial number: AUZ8ZDDD001TUXZ System description: E380 BDT C7 Software number: 4G2919612Q Software version: 0204 Hardware version: H11 Serial number: 90349MG10001A System description: CD-Database Software number: 8R0060961F Software version: 5298 Trouble codes: 03276 - Checking software version management static Priority: 6 Frequency counter: 1 Driving cycle: 191 Mileage: 132847 km Date: 2020-06-19 20:01:53 03623 - Release code faulty static Priority: 6 Frequency counter: 1 Driving cycle: 191 Mileage: 132847 km Date: 2020-06-19 20:01:52 --------------------------------------------------------------- 62 Rear Left Door System description: TSG HL Software number: 4G8959795J Software version: 0507 Hardware number: 4G8959795G Hardware version: H03 Serial number: -------------- Long coding: 010F14004001628002080002 Trouble codes: No trouble codes found --------------------------------------------------------------- 69 Trailer Control System description: Anhaenger Software number: 4G8907383 Software version: 0100 Hardware number: 4G8907383 Hardware version: H11 Serial number: 00000193762419 Long coding: 0109080000000000 Trouble codes: No trouble codes found --------------------------------------------------------------- 6C Rear View Camera Software number: 4G0907441B Software version: 0061 Hardware number: 4H0907441 Serial number: 525 PA8J36G2TF Coding: 1090005 Trouble codes: No trouble codes found --------------------------------------------------------------- 6D Deck Lid Control System description: HDSG-Modul Software number: 4G9959107B Software version: 0143 Hardware number: 4G9959107A Hardware version: H03 Serial number: 179300549 ODX name: EV_HDSGAu572 ODX version: 001022 Long coding: 097205C011 Trouble codes: No trouble codes found --------------------------------------------------------------- 72 Rear Right Door System description: TSG HR Software number: 4G8959795J Software version: 0507 Hardware number: 4G8959795G Hardware version: H03 Serial number: -------------- Long coding: 010F14004001628002080002 Trouble codes: No trouble codes found --------------------------------------------------------------- 85 On Board Camera System description: DPC-SG Software number: 4G0907217A Software version: 0038 Hardware number: 4H0907217A Hardware version: H26 Serial number: 26213002542100000000260012 ODX name: EV_OnBoardCamerDPC ODX version: 001007 Long coding: EE060000 Trouble codes: U111300 - Function limitation due to received malfunction value static Date: 2020-06-20 15:36:46 Mileage: 132860 km Priority: 6 Malfunction frequency counter: 1 Unlearning counter: 192 Control module temperature: 52.0 °C Voltage terminal 15: 14.3 V Outside air temperature: -39.5 °C --------------------------------------------------------------- 8B Adaptive Cruise Control System description: ACC3 Software number: 4G0907541A Software version: 0400 Hardware number: 4G0907541 Hardware version: H19 Serial number: 00000000000000 ODX name: EV_AdaptCruisContr2AU57X ODX version: 002008 Long coding: 7F04010202 Trouble codes: No trouble codes found --------------------------------------------------------------- 8E Image Processing System description: BV-SG Software number: 4G0907107E Software version: 0041 Hardware number: 4H0907107 Hardware version: H31 Serial number: 00500012210613769103370000 ODX name: EV_BC7 ODX version: 001001 Long coding: 04C23A1C1111 Trouble codes: C110800 - Function limitation due to missing image information static Date: 2020-06-20 15:36:48 Mileage: 132860 km Priority: 6 Malfunction frequency counter: 2 Unlearning counter: 192 Voltage terminal 15: 14.3 V Control module temperature: 29.0 °C Outside air temperature: 21.0 °C --------------------------------------------------------------- 8F Pretensioner Left System description: RGS-VL Software number: 4H0980945B Software version: 0080 Hardware number: 4H0980945C Hardware version: H13 ODX name: EV_RGS_L ODX version: 002004 Long coding: 0066E608031F0376070308004240C2010000 Trouble codes: No trouble codes found --------------------------------------------------------------- 90 Pretensioner Right System description: RGS-VR Software number: 4H0980946B Software version: 0080 Hardware number: 4H0980946C Hardware version: H13 ODX name: EV_RGS_R ODX version: 002004 Long coding: 0066E608031F0376070308004240C2010000 Trouble codes: No trouble codes found --------------------------------------------------------------- A9 Structure Borne Sound System description: SAS-GEN 2 Software number: 4G0907159A Software version: 0005 Hardware number: 4H0907159A Hardware version: H06 Serial number: 130613201659�� ODX name: EV_SoundActuaGen2AU64X ODX version: 002005 Trouble codes: No trouble codes found --------------------------------------------------------------- C0 Exterior Noise System description: SAS-GEN 2 AGA Software number: 4G0907160B Software version: 0004 Hardware number: 4G0907160B Hardware version: H09 Serial number: 130618200598 ODX name: EV_ActuaForExterNoiseUDS ODX version: 003013 Trouble codes: No trouble codes found

Me again! Now yet another error appearing - well three - on the dash - all yellow and all adaptive systems. Nothing has been done to the car apart from new discs and shoes all round. Driving to shop (7 miles away) and back, at about 9 miles the air suspension light comes on - rapidly followed by the adaptive headlamp failure and then the ACC and Brake . I drive home and try changing car height - works - each driving mode works. Plug in and clear all codes - nope. Switch off and clear again - all clear. No issues when starting. Just now - been on a short run - and at about 8 miles all three again. Home and tried to clear. Same cycle as yesterday. So - layman's theory - these are all adaptive systems, so probably some sensor issue. Or is it related to having new brakes on the front, and I doubt any calibration took place after installation, if that was necessary. So - A6 hivemind - anyone had this, or anyone know what to look for? For ref (edited down) 04 Steering Angle Sensor Trouble codes: No trouble codes found 09 Central Electrics Trouble codes: 01771 - Headlamp range control module Please read DTC static 34 Chassis Control Trouble codes: C103515 - Right front level control sensor Open circuit/short circuit to B+ static 55 Headlight Regulation Trouble codes: U111200 - Function limitation due to implausible message static 85 On Board Camera Trouble codes: U111300 - Function limitation due to received malfunction value static

OK, I'll try to get a pic!! Thanks.

One final thing - and I don't think it's falling at the first hurdle - but all filters sourced and fine - but fuel filter seems to come in various flavours - but OEM numbers seem the same. Am I safe to get any (Bosch have three) or is there a way I can check the exact part number I have installed? Bah!

See my Adaptive Cruise Control post!! Honestly, the local garage is spitting feathers as it was their warranty that paid Audi to NOT diagnose the problem. I ended up doing it with ODBEleven and forums. Water in the GPS fin. I'll keep you posted on how it goes.

Great tips, the YouTube stuff is good, but these wee tips really help. Going to look at the parts online now and do price comparisons.

Haha. On another note, I have just been looking at the DIY option of servicing - oil change and all filters. If I use an oil extractor through the dipstick pipe, I don't need to jack it up. Just need to remember who I lent my torque wrench to!

I have Brembo rear and Pagid front. I was talking to a friend with a beemer and he rates the Pagid stuff he puts on his car. But, they are on now, so proof of the pudding and all that!! !Removed! massive buggers too.

Thanks Gareth. These names are what I was after. I used Eurocarparts (online) for my discs and pads - very reasonable indeed, and Pagid/Brembo. But I'll go with the parts and oil. Thanks so much. I'd love to do it all, but as with Steve, I'd be in my drive, and I no longer have a trolley jack...

You are too kind. I had a TVR Tuscan, and you couldn't get into the engine. It was in the 'second' bonnet, that was sealed. You could add water to the radiator and top up oil! That was a great car, no driving assists...haha. But the price of a set of tyres! I'll see what Europarts is offering on it's latest DFS sale, and maybe get the parts...Though there's a very good chap round the corner. The Scottish Borders is the land of the Jim Clark Rally, and he's an ex-rally mechanic, so I trust him.

When I bought it in November, it had 'just been serviced'. The local garage are very thorough, but I've not done enough miles to trigger the Audi service warning. I've done about 5k since I bought it - it's now at 81k. So I imagine they did the filters and oils. I can check with them. As for Steve's reply, I would love to service it myself - I miss working on my old Lightweight Landrover...but the two vehicles are poles apart!

The Audi dealer/workshop service costs are very high. Especially when you look at the cost of brake pad renewal and extrapolate the rest! I got some Pagid discs and pads recently and got them fitted locally for a third of the cost. That said. I need a service in 1000 miles, or so I am being told by the HUD. What should I ask the local garage to do? I have the BiTdi Allroad. Thanks in advance...

I got the direct downloads and they all worked!

Did you get direct download, or SD cards sent to you?

Gareth, All done - it WAS the GPS fin. Local garage fitted a new one, the old one was corroded inside. Why Audi didn't check that when it came up on the scan!!? N A completely clear scan now...nothing at all. Amazing how water ingress into the fin caused a bevvy of issues.

Gareth, All done - it WAS the GPS fin. Local garage fitted a new one, the old one was corroded inside. Why Audi didn't check that when it came up on the scan!!? N A completely clear scan now...nothing at all. Amazing how water ingress into the fin caused a bevvy of issues.

Hello, I have a full scan from the OBDEleven I bought. Is there anyone who can look at it and check the error codes etc.? T

It is actually the garage I got it off who asked me if I knew of anyone with the new RossTech thing... Anyway, regardless of the outcome of this I will still be the owner of a VAG car one way or the other, so I have bought the OBDEleven bluetooth connector and now have a full output of codes to pass to the garage... That said - here they are for the hivemind...anything jumps out, please say! OBDeleven data log Date: 2020-01-26 13:22 VIN: XX Car: Audi A6 Allroad Year: 2014 Body type: Avant Engine: CGQB 230 kW (313 HP) 3.0 l Mileage: 126373 KM --------------------------------------------------------------- 01 Engine Control Module 1 System description: 3.0BTD EDC17 Software number: 4G0907589C Software version: 0001 Hardware number: 4G0907589 Hardware version: H25 ODX name: EV_ECM30BTD0114G0907589C ODX version: 001001 Long coding: 322A403225760B020000 Trouble codes: No trouble codes found --------------------------------------------------------------- 02 Transmission Control Module System description: 0BK 30RTDIRdW Software number: 4G0927158L Software version: 1003 Hardware number: 0BK927156AM Hardware version: H16 ODX name: EV_TCMAL551211 ODX version: 002022 Long coding: 000001 Trouble codes: No trouble codes found --------------------------------------------------------------- 03 Brakes 1 System description: ESP PREMIUM Software number: 4G0907379M Software version: 0450 Hardware number: 4G0907379M Hardware version: H09 Serial number: -------------- ODX name: EV_ESPPremiAU57X ODX version: 004039 Long coding: 49A7DF0592E5FBA0FB00 Trouble codes: No trouble codes found --------------------------------------------------------------- 04 Steering Angle Sender Trouble codes: No trouble codes found --------------------------------------------------------------- 05 Kessy System description: BCM2 2.0 Software number: 4H0907064CN Software version: 0433 Hardware number: 4H0907064CN Hardware version: H33 Long coding: 01B93046000000000000 Subsystems: System description: J764 ELV MLB Software number: 4H0905852C Software version: 0046 Hardware version: H40 Serial number: 2313000106737005 Trouble codes: No trouble codes found --------------------------------------------------------------- 08 Air Conditioning System description: KLIMA 4 ZONEN Software number: 4G0820043AD Software version: 0087 Hardware number: 4G0820043AD Hardware version: H13 Serial number: 22061300040258 ODX name: EV_AirCondiComfoUDS ODX version: 002040 Long coding: 3622007825 Trouble codes: U111300 - Function limitation due to received malfunction value static Date: 2020-01-25 17:23:42 Mileage: 126373 km Priority: 6 Malfunction frequency counter: 1 Unlearning counter: 98 Dynamic environmental data: 02860C31260973261312FC B109E13 - A/C compressor first run Open circuit static Date: 2020-01-25 17:23:42 Mileage: 126373 km Priority: 6 Malfunction frequency counter: 1 Unlearning counter: 98 Dynamic environmental data: 02860C31260973261312FC B126411 - Windshield defogger activation Short circuit to ground static Date: 2020-01-25 17:23:42 Mileage: 126373 km Priority: 6 Malfunction frequency counter: 1 Unlearning counter: 98 Dynamic environmental data: 02860C31260973261312FC B126412 - Windshield defogger activation Short circuit to B+ static Date: 2020-01-25 17:23:42 Mileage: 126373 km Priority: 6 Malfunction frequency counter: 1 Unlearning counter: 98 Dynamic environmental data: 02860C31260973261312FC --------------------------------------------------------------- 09 Central Electrics System description: BCM1 2.0 Software number: 4H0907063CE Software version: 0130 Hardware number: 4H0907063E Hardware version: H12 Serial number: 00000001745791 Long coding: 0200201050B49FE2C98100C000001908CF9D67082F080201000008406100 Subsystems: System description: WWS57X 130618 Software number: 4G2955119 Software version: 0080 Hardware version: H36 Serial number: 130620152538 Long coding: 0045F7 System description: G397_RLFS Software number: 8U0955559B Software version: 0002 Hardware version: H06 Serial number: 21462662 Long coding: 02006D System description: E1 - LDS Software number: 4G0941531S Software version: 0044 Hardware version: H07 Serial number: 28 06 2013 00001337 System description: AQ_Hum_Sensor Software number: 4H0907658 Software version: 0003 Hardware version: H03 Serial number: 7719C4B6000000000001 Trouble codes: 01229 - Humidity sensor, A/C system Faulty static Priority: 3 Frequency counter: 1 Driving cycle: 98 Mileage: 126373 km Date: 2020-01-25 17:23:00 --------------------------------------------------------------- 10 Parking Assistance 2 System description: PARKHILFE PLA Software number: 4H0919475AB Software version: 0060 Hardware number: 4H0919475E Hardware version: H06 Serial number: 56261318003980 ODX name: EV_EPHVA2CAU57X0000 ODX version: 002012 Long coding: B93B0C Trouble codes: No trouble codes found --------------------------------------------------------------- 13 Adaptive Cruise Control System description: ACC3 Software number: 4G0907561A Software version: 0410 Hardware number: 4G0907561 Hardware version: H19 Serial number: 00000000000000 ODX name: EV_AdaptCruisContrAU57X ODX version: 002010 Long coding: 7F04010202 Trouble codes: U111300 - Function limitation due to received malfunction value Intermittent Date: 2020-01-25 17:23:43 Mileage: 126373 km Priority: 6 Malfunction frequency counter: 2 Unlearning counter: 138 Dynamic environmental data: 028D000B02852EDA100EFFFD100FFDE8 --------------------------------------------------------------- 15 Airbag System description: Airbag10.43 Software number: 4H0959655C Software version: 0040 Hardware number: 4H0959655C Hardware version: H43 Serial number: 003JG00DVSXE ODX name: EV_AirbaAU10BPAAU64X ODX version: 001014 Long coding: 3032343631334E303539554A305234473053 Trouble codes: No trouble codes found --------------------------------------------------------------- 16 Steering Column Electronics System description: Lenks.Modul Software number: 4H0953568G Software version: 0005 Hardware number: 4H0953568G Hardware version: H04 Serial number: 90372MFR001G3 Long coding: 0000FD Subsystems: System description: E221 - MFL Software number: 4G0951528E Software version: 0010 Hardware version: H09 Serial number: 22 05 2013 33011847 Trouble codes: No trouble codes found --------------------------------------------------------------- 17 Dash Board System description: TDieGb AccNv Software number: 4G9920950P Software version: 0618 Hardware number: 4G9920950P Hardware version: H80 Serial number: 6581406135960075 ODX name: EV_RBD4K ODX version: 004048 Long coding: 338620081F512600010600 Trouble codes: No trouble codes found --------------------------------------------------------------- 19 Gateway System description: J533--Gateway Software number: 4G0907468AC Software version: 0037 Hardware number: 4G0907468AC Hardware version: H12 Serial number: 00000000999979 ODX name: EV_GatewPkoUDS ODX version: 001018 Long coding: 00CD077D00 Subsystems: System description: J367-BDMHella Software number: 8T0915181 Software version: 8041 Hardware version: H03 Serial number: 8141390603 Trouble codes: U140600 - Static current too high Intermittent Date: 2020-01-25 19:30:08 Mileage: 126373 km Priority: 7 Malfunction frequency counter: 2 Unlearning counter: 138 Voltage terminal 30: 12.5 V Voltage terminal 15: 0.0 V Control module temperature: 15 °C System status: LIN_active Terminal 15 status: Off Terminal 15 status via CAN: Off IN ZAS_Kl_X: Off Engine running: Off IN ESP_Stillstandsflag: no standstill detected Datenfeld: 0 U140B00 - Energy management active Intermittent Date: 2020-01-25 22:33:19 Mileage: 126373 km Priority: 7 Malfunction frequency counter: 1 Unlearning counter: 138 Voltage terminal 30: 12.4 V Voltage terminal 15: 0.0 V Control module temperature: 10 °C System status: Awake_Timer_active Terminal 15 status: Off Terminal 15 status via CAN: Off IN ZAS_Kl_X: Off Engine running: Off IN ESP_Stillstandsflag: no standstill detected Datenfeld: 1 --------------------------------------------------------------- 28 Climate Control Unit Rear System description: KLIMA FOND Software number: 4G0919158J Software version: 0087 Hardware number: 4G0919158J Hardware version: H07 Serial number: 03071300040346 ODX name: EV_ClimaContrUnitRearUDS ODX version: 002019 Long coding: 22 Trouble codes: B10D322 - Left rear upper body vent motor Upper limit exceeded static Date: 2020-01-26 13:18:02 Mileage: 126373 km Priority: 3 Malfunction frequency counter: 1 Unlearning counter: 98 Dynamic environmental data: 02860BAC26097226A62EE92EE92C902710 B10D422 - Right rear upper body vent motor Upper limit exceeded static Date: 2020-01-26 13:18:03 Mileage: 126373 km Priority: 3 Malfunction frequency counter: 1 Unlearning counter: 98 Dynamic environmental data: 02860BB126097226A72EDD2EDD2C842710 --------------------------------------------------------------- 34 Ride Control System System description: LUFE-DAEMPFER Software number: 4G0907553F Software version: 0782 Hardware number: 4G0907553F Hardware version: H18 Serial number: �‰ST ODX name: EV_AirSuspe ODX version: 003024 Long coding: 008003 Trouble codes: No trouble codes found --------------------------------------------------------------- 3B Sensor Electronics System description: SARA 6D Software number: 4G0907637K Software version: 0056 Hardware number: 4G0907637F Hardware version: H02 Serial number: EJ1BPA82044ZLP���������� ODX name: EV_SARA2 ODX version: 005012 Trouble codes: No trouble codes found --------------------------------------------------------------- 3C Lane Change Assistant System description: J769 SWA MasterH04 Software number: 4G0907566E Software version: 0040 Hardware number: 4G0907566 Serial number: 6PZ 010 287-04 Coding: 0011104 Subsystems: System description: J770 SWA Slave H04 Software number: 4G0907568E Software version: 0040 Trouble codes: No trouble codes found --------------------------------------------------------------- 42 Door Electronics Driver Side System description: TSG FA Software number: 4G8959793H Software version: 0507 Hardware number: 4G8959793F Hardware version: H04 Serial number: -------------- Long coding: 011F16005C01628002080013 Trouble codes: No trouble codes found --------------------------------------------------------------- 44 Steering Assistance System description: RCEPS Software number: 4G0909144L Software version: 0010 Hardware number: 4G0909144G Hardware version: H38 Serial number: 0029630591 ODX name: EV_RCEPS ODX version: 009008 Long coding: 101101010000 Trouble codes: No trouble codes found --------------------------------------------------------------- 46 Central Module Comfort System System description: BCM2 2.0 Software number: 4H0907064CN Software version: 0433 Hardware number: 4H0907064CN Hardware version: H33 Serial number: 0310530050 Long coding: 013B0622A0B93080832009042C010F470000000000000000000000000000 Subsystems: System description: DWA-Sensor Software number: 4G0951177 Software version: 0010 Hardware version: H01 System description: LIN BACKUP HO Software number: 1K0951605C Software version: 1501 Hardware version: H05 Trouble codes: No trouble codes found --------------------------------------------------------------- 47 Sound System System description: BOSE-G3-C7 Software number: 4G0035223C Software version: 0160 Hardware number: 4G0035223A Hardware version: H07 Serial number: 00000000019648 Long coding: 030000 Trouble codes: No trouble codes found --------------------------------------------------------------- 52 Door Electronics Passenger Side System description: TSG BF Software number: 4G8959792J Software version: 0507 Hardware number: 4G8959792G Hardware version: H03 Serial number: -------------- Long coding: 011F16005E01628002080002 Trouble codes: No trouble codes found --------------------------------------------------------------- 53 Parking Brake System description: EPB-4 Software number: 4H0907801L Software version: 0017 Hardware number: 4H0907801A Hardware version: H05 Serial number: 00000002610471 ODX name: EV_ParkiBrake ODX version: 001029 Trouble codes: No trouble codes found --------------------------------------------------------------- 55 Headlight Regulation System description: ....AFS13.... Software number: 4H4907357C Software version: 0020 Hardware number: 4H4907357A Hardware version: H01 Serial number: 130628-0004-0076 ODX name: EV_AdvanFrontSyste ODX version: 005001 Long coding: 11226F33F918EB00 Trouble codes: No trouble codes found --------------------------------------------------------------- 56 Radio System description: Radio U DAB Software number: 4G0035061L Software version: 0133 Hardware number: 4G0035061 Hardware version: H60 Serial number: 109GB0D7689099 Long coding: 010103010000000001 Trouble codes: No trouble codes found --------------------------------------------------------------- 5F Information Control Unit 1 System description: H-BNT-EU Software number: 4G0035670K Software version: 0732 Hardware number: 4G0035670H Hardware version: H51 Serial number: 190G$0D7544157 Long coding: 080101050003F9EF3D90EB3E00000003000001000200000000 Subsystems: System description: EUR 2013/2014 Software number: 8R0060884BC Software version: 1603 System description: DU8 C7 SV Software number: 4G0919605C Software version: 0021 Hardware version: H43 Serial number: AUZ8ZDDD001TUXZ System description: E380 BDT C7 Software number: 4G2919612Q Software version: 0204 Hardware version: H11 Serial number: 90349MG10001A System description: CD-Database Software number: 8R0060961F Software version: 5298 Trouble codes: 00862 - Navigation antenna (GPS) Open circuit Intermittent Priority: 5 Frequency counter: 1 Driving cycle: 138 Mileage: 126373 km Date: 2020-01-25 17:24:03 --------------------------------------------------------------- 62 Door Electronics Rear Left System description: TSG HL Software number: 4G8959795J Software version: 0507 Hardware number: 4G8959795G Hardware version: H03 Serial number: -------------- Long coding: 010F14004001628002080002 Trouble codes: No trouble codes found --------------------------------------------------------------- 69 Trailer Function System description: Anhaenger Software number: 4G8907383 Software version: 0100 Hardware number: 4G8907383 Hardware version: H11 Serial number: 00000193762419 Long coding: 0109080000000000 Trouble codes: No trouble codes found --------------------------------------------------------------- 6C Camera System Rear View System description: SG Rueckfahrkamera Software number: 4G0907441B Software version: 0061 Hardware number: 4H0907441 Serial number: 525 PA8J36G2TF Coding: 1090005 Trouble codes: No trouble codes found --------------------------------------------------------------- 6D Deck Lid Control Unit System description: HDSG-Modul Software number: 4G9959107B Software version: 0143 Hardware number: 4G9959107A Hardware version: H03 Serial number: 179300549 ODX name: EV_HDSGAu572 ODX version: 001022 Long coding: 097205C011 Trouble codes: B12EF54 - Luggage compartment cover No basic setting static Date: 2020-01-25 17:23:55 Mileage: 126373 km Priority: 2 Malfunction frequency counter: 1 Unlearning counter: 98 Voltage terminal 30: 12.09 V --------------------------------------------------------------- 72 Door Electronics Rear Right System description: TSG HR Software number: 4G8959795J Software version: 0507 Hardware number: 4G8959795G Hardware version: H03 Serial number: -------------- Long coding: 010F14004001628002080002 Trouble codes: No trouble codes found --------------------------------------------------------------- 85 On-Board Camera System description: DPC-SG Software number: 4G0907217A Software version: 0038 Hardware number: 4H0907217A Hardware version: H26 Serial number: 26213002542100000000260012 ODX name: EV_OnBoardCamerDPC ODX version: 001007 Long coding: EE060000 Trouble codes: No trouble codes found --------------------------------------------------------------- 8B Adaptive Cruise Control 2 System description: ACC3 Software number: 4G0907541A Software version: 0400 Hardware number: 4G0907541 Hardware version: H19 Serial number: 00000000000000 ODX name: EV_AdaptCruisContr2AU57X ODX version: 002008 Long coding: 7F04010202 Trouble codes: U111300 - Function limitation due to received malfunction value Intermittent Date: 2020-01-25 17:23:59 Mileage: 126373 km Priority: 6 Malfunction frequency counter: 1 Unlearning counter: 138 Dynamic environmental data: 028D000C02852EA9100EFFFE100FFDEA --------------------------------------------------------------- 8E Image Processing Electronics System description: BV-SG Software number: 4G0907107E Software version: 0041 Hardware number: 4H0907107 Hardware version: H31 Serial number: 00500012210613769103370000 ODX name: EV_BC7 ODX version: 001001 Long coding: 04C23A1C1111 Trouble codes: No trouble codes found --------------------------------------------------------------- 8F Pretensioner Front Left System description: RGS-VL Software number: 4H0980945B Software version: 0080 Hardware number: 4H0980945C Hardware version: H13 ODX name: EV_RGS_L ODX version: 002004 Long coding: 0066E608031F0376070308004240C2010000 Trouble codes: No trouble codes found --------------------------------------------------------------- 90 Pretensioner Front Right System description: RGS-VR Software number: 4H0980946B Software version: 0080 Hardware number: 4H0980946C Hardware version: H13 ODX name: EV_RGS_R ODX version: 002004 Long coding: 0066E608031F0376070308004240C2010000 Trouble codes: No trouble codes found --------------------------------------------------------------- A9 Actuator For Structure-Borne Sound System description: SAS-GEN 2 Software number: 4G0907159A Software version: 0005 Hardware number: 4H0907159A Hardware version: H06 Serial number: 130613201659�� ODX name: EV_SoundActuaGen2AU64X ODX version: 002005 Trouble codes: No trouble codes found --------------------------------------------------------------- C0 Actuator For Exterior Noise System description: SAS-GEN 2 AGA Software number: 4G0907160B Software version: 0004 Hardware number: 4G0907160B Hardware version: H09 Serial number: 130618200598 ODX name: EV_ActuaForExterNoiseUDS ODX version: 003013 Trouble codes: No trouble codes found

I have had the 'ACC and Brake Guard unavailable' error since December - it's been into Audi in Edinburgh and Glasgow and although they fitted new ABS sensor - this message has not gone away. I have seen others posting a full VAGCOM in other posts regarding this issue - I would like to do the same, but do not have access to the kit. Anyone in Glasgow who has one, or know of someone who does? Are the eBay unbranded ones as good as the branded one? I just need to check the faults that seem to be mentioned for this fault - door locks and GPS fin. Thanks Thomas
